Generación de archivos STL desde formatos CAD para imprimir en 3D


Para poder imprimir un modelo en una impresora 3D es necesario generar antes el formato STL correspondiente. STL (de estereolitografía) es un formato de fichero que prácticamente todos los programas de control de impresoras 3D aceptan.

6cdc55dc759947ae



Muchos, sin embargo, hemos tenido problemas a la hora de generar estos ficheros partiendo de nuestro diseño y luego, al imprimirlos en 3D, el resultado no ha sido el deseado.

La siguiente guía debería ayudaros a resolver estos problemas y obtener ficheros STL perfectos, listos para enviar a vuestra impresora 3D.

SolidWorks

* File > Save As
* Set Save As Type to STL
* Options > Fine > OK
* Save
* STL settings: How to change STL settings
* File > Save As
* STL > Options
* For a smoother STL file, change the Resolution to Custom
* Change the deviation to 0.0005in (0.004 mm)
* Change the angle to 5 (Smaller deviations and angles will produce a smoother file, but the file size will get larger)

Pro/ENGINEER

* File > Export > Model
* STL
* Set chord height to 0. The field will be replaced by minimum acceptable value.
* Set Angle Control to 1
* OK

Catia

* Select STL command
* Maximum Seg to 0.015mm
* Select the model and > select Yes
* Select Export > type File name > OK

IronCAD

* Richt Click on the part
* Part properties > Rendering
* Set Facet Surface smoothing to 150
* File > Export
* Choose .STL

McNeel Rhino

* File > Save As
* Select File Type to STL
* Select File Name > Save
* Select Binary
* Select Detail Controls from Mesh Options
* Max Angle = 20, Max aspect ration = 6, Min edge Length = 0.0001
* OK

UGS NX

* File > Export > Rapid Prototyping
* Output type : Binary
* Triangle & Adjacency Tolerance: 0.015 mm
* Set Auto normal Gen to ON
* Set Normal Display to ON
* Set Triangle Display to ON
* File Header Information: Press OK
* In case a error messages “Negative coordinates found” appears, it can be ignored

Solid Edge

* Open Model & select File > Save As
* Select File type as STL
* Options > conversion tolerance to 0.015 mm
* Surface Plane Angle > 45°
* Select Binary type and OK
* Name & Save STL file

AutoDesk Inventor

* Go to the File menu, then select the ‘Save Copy As’ option
* Select STL from the Types drop-down
* Click the Options button, and choose the High detail level
* Click the Save Button
